Bolong company is a manufacturer focusing on the professional research and development of livestock and poultry waste treatment equipment, with a number of independent invention patents, utility model patents, etc. In recent years, we have been focusing on the progress of harmless, resourceful and ecological treatment of livestock and poultry manure at home and abroad, and have extensively researched the domestic and foreign advanced equipments and technologies, combined with our more than 20 years of experience in breeding, and introduced talents in the fields of mechanical design, mechanical manufacture, senior At the same time, we have introduced talents in mechanical design, mechanical manufacturing, senior technical management and other aspects, forming a high-quality, professional, reasonable structure, solid foundation of the technical research and efficient management team. composting machine is one of Bolong’s main equipment for harmless treatment of livestock and poultry manure.

1. Structure of optimized space utilization poultry composting machine

The structure of the whole good quality commercial composting machine is divided into three parts, the base of the lower part of the distribution of the hydraulic station, scroll air pump, cylinder, heating system and mixing shaft, etc.; the middle of the double-layer insulated tanks, automatic control system, export devices, etc., the inner wall of the tank adopts 304 stainless steel plate village, effectively extend the life of tanks and reduce the residue of rotting material, the middle of the polyurethane cool foam filled with insulation, the outer wall of the thickening of the steel sheet as a support! Tank: the upper part is composed of storm shelter, testing platform and exhaust facilities and other devices. Attached equipment are automatic bucket elevator, exhaust gas filtration and deodorization system and heat exchange system.

2. Composting machine operation principle

Bolong good quality commercial composting machine, suitable for different manure, livestock and poultry carcasses, food waste, domestic sewage sludge treatment, organic waste moisture as long as below 70%, without adding any auxiliary materials, can be put directly into the tank. The custom sizes available commercial composting machine can adapt to the high humidity, high temperature of different regions. The use of vertical makes the professional composting machine adapted to different regions with high humidity and high cold, and adopts vertical closed tank structure, which reduces the installation area. The safe and reliable commercial composting machine adopts aerobic microorganisms aerobic fermentation principle, so that microorganisms use the organic matter and residual protein in livestock and poultry manure and carcasses, in a certain temperature, humidity and sufficient oxygen environment, rapid reproduction, so as to realize the harmless treatment of livestock and poultry waste.

It is a continuous system that can put waste every day and organic fertilizer is output every day. The bucket elevator lifts the organic waste and puts it into the environmentally sustainable industrial composting machine automatically. The organic waste is mixed in the tank by means of mixing blades. A special heat exchanger uses the heat from the waste gases to heat up fresh air and bring it into the tank, where the hot air is blown through holes in the blades. The warm air accelerates the aerobic fermentation of the organic waste and the evaporation of water. After an average of one week, the organic waste is converted into high quality organic fertilizer.

3. Advantages of Bolong variety of sizes commercial composting machine design

① Sealed feeding

Livestock and poultry manure is transported to the livestock and poultry manure treatment center by the closed chicken manure conveyor to ensure that the manure does not fall to the ground, does not come into contact with the air to cause air pollution, and ensures that there is no foul smell.

② Tank closed

the tank is fully closed, the fermentation process is not affected by the natural environment temperature, humidity, so that the production of organic fertilizer to meet the industrial production standards, to prevent the leakage of waste gas produced by the fermentation, to eliminate secondary pollution.

③ Heat insulation treatment

The internal tank adopts high-performance heat preservation material, which is little affected by the outside world and ensures year-round fermentation.

④ Heat exchange device

The heat exchange device can make full use of the high temperature gas naturally generated inside the tank, and carry out preliminary heating and warming of the inhaled air, which improves the energy utilization rate, ensures the fermentation effect, reduces the power consumption of the professional composting machine, and realizes the purpose of energy saving and consumption reduction.

⑤ Hydraulic drive

Hydraulic drive is adopted, with large thrust force, which can ensure the full load operation of decayed materials in the tank, ensuring safe and reliable operation and low maintenance cost; the transmission power is large, low-speed, smooth, with overload protection capability and flexible transmission arrangement.

Bolong in line with the “user satisfaction is the success of Bolong” business philosophy, in addition to the use of advanced and reliable composting machine, reasonable and perfect technology and other hardware, more complete training means, quality service system as a backing, to ensure that Bolong machinery built the quality of the project, and at the same time reduce the production of energy consumption and maintenance costs, so that the user in the fierce market competition. This will make users invincible in the fierce competition in the market. If you have any questions or want to know more about global leadership industrial composting machine, please feel free to contact us, we have a professional technical team and service team ready to serve you!
